RADWIN5000ConfigurationGuide Release4.9.17 3‐26
RegisteringafixedHSUforservice InstallingaSector
11. ClickRegistertocompletetheprocess.Hereisatypicalresult:
Figure3‐5:AregisteredHSUcard‐extendedview
Observethefollowing:
a. TheregisteredHSUiconLEDisnowgreen.
b. CIRappearsinthetoprightoftheHSUcard,indicatingthattheresource
typefortheHSUisCommittedInformationRate.
c. TheATPCStatustriangleshowsgreen‐indicatingthatthedynamicrange
andratehavebeenachieved(seeCards‐TableViewonpage 2‐9).
d. SincewehaveenabledRSSExtendedViewinPreferences(seeEnableRSS
ExtendedView),theradiosignalstrengthforeachantennaisshown.
e. Themaximumpossiblethroughputisshownhere.IftheMIMOmode
choseninStep6.wasDiversity,thisvaluewouldbesmaller.
(a) (b)
(c)
(g:sector‐wide)
(d)
(e)
(g)
(f)
