RADWIN5000ConfigurationGuide Release4.9.17 2‐9
TableView RADWINManagerOverview
Cards‐TableView
TheindividualHSUdisplayboxesarecalledcards.
Figure2‐11:HSUCards
TitleBar:ShowsHSUnameandservicecategory(BEorCIR)
IP&Loc:IPaddressandlocationasdefinedduringConfiguration orRegistration
ATPCtriangle:IndicatestheATPCmode(StaticorDynamic)andstatusofATPCforthisHSU.
Possiblestatesare:
RSS: RadiosignalstrengthforboththeHBSandHSUareshownasbargraphs.
• Theyshouldbebalanced.IfforoneHSUthereisaconsistentimbalanceofeven
1dBMorintermittentimbalancesof2‐3dBm,checkitsantennaconnectionsand
perhapstheunititself.Ifsever alHSUsareoutofbalance,theremaybeaproblem
withtheHBS.
• YoucanalsosetanextendedRSSdisplay,showingtheRSSforeachantenna(ifrel‐
evant).SeeSettingRADWINManagerPreferences,Advancedbelow.
ThroughputDownlinkandUplink:
Thelightbluepartofeachbarshowsthepeakthroughputpossible,subjecttotraffic
conditions.
Thegreenpartofeachbarshowsthecommittedinformationrate,andonlyappears
foranHSUwhoseresourcetypeisdefinedasCIR(CommittedInformationRate).

BestEffortHSU CommittedInformationRate
HSU,withextendedRSSdisplay
Green
Dynamicrangeandrate
achieved
Optimizedtransmitpowerandtransmitdata
ratehavebeenachievedforthisHSU.
Yellow
Dynamicrangeandrate
notachieved
Systemistryingtoachieveoptimizedtransmit
powerandtransmitdatarateforthisHSU.
Red
Dynamicrangeandrate
notaccordingtothe
requestedvalue
Systemwasnotabletoachiev
eoptimized
transmitpowerortransmitdatarateforthis
HSU.
TitleBar
IPAddress,Loc
RSS
Level(nomadic)
ATPCtriangle
Throughput

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
