RADWIN5000ConfigurationGuide Release4.9.17 2‐10
TableView RADWINManagerOverview
IftheMaximumInformationRateortheResourceAllocationwaschangedduring
registration,thesevalueswillappearasshown(seeRegisteringafixedHSUfor
serviceonpage 3‐21.formoredetails):
RxandTxrates:AtthebottomofthecardaretheEthernetreceiveandtransmitratesforthe
HSU.Thelittleballonthetopleftofeachcardisastatuslight,explainedinTable 2‐6below.
(Peakthroughput)
(CommittedInformation
Rte)
(Resource
(Max.Info.Rate)
Allocation)
