RADWIN5000ConfigurationGuide Release4.9.17 2‐18
BaseStationPanel RADWINManagerOverview
Figure2‐18:BaseStationdetailPanel
Activate:Appearsintheheaderifthebasestationisnotactivated.
ProductName:Asorderedfromyoursupplier
AntennaType:DualorSingle
IPAddress:BaseStationIPaddress
SubnetMask:BaseStationsubnetmask
TxRatio:ShowstheallocationofthroughputbetweendownlinkanduplinktrafficattheHBS.
Hereitissetto49.5%downlinkand50.5%uplink.TheTxRatioisnotonlysector‐wide:Ifyou
useanHSStocollocateseveralHBSs(tocoveradjacentsectors),theymustall usethesameTx
Ratio.
CIR/BERatio:Showswhatpercentageofre sourcesinthesectorisusedforCIRtraffic,and
whatper centageisusedbyBEtraffic.
RxRateandTxRate:EthernettrafficreceiveandtransmitratesthroughtheHBSunderload.
Table2‐5:HBSDetailPanelbuttonbarfunctions
Menu
Icon
Purpose CrossRef erence
HBSConfiguration ConfiguringanHBS
RecentEventsLog RecentEvents
PerformanceMonitor PerformanceMonitoring
ActiveAlarms ActiveAlarms
SpectrumView SpectrumView
De‐activatedBaseStationindication

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
