Radwin 5000 User Manual

RADWIN5000ConfigurationGuide Release4.9.17 4‐37
RADIUS ManagingtheSector
• Serialnumber(acquiredfromyourvendor,seeInventoryonpage 4‐52)
• Name
• Location
• VLANidentifier(ifrelevant)
• RegisterAvailability(whetherornottoregisterthisspecificHSU)
• Desiredservicecategory
4. Preparetheservicecategorydefinitionsthatyouwi ll setusingtheRADWIN
Manager(seeRADIUSonpage 4‐35).Upto8categoriescanbedefined;each
categorysetsthefollowingparameters:
• UplinkResources
• DownlinkResources
• ResourceType(CIRorBestEffort)
• MaximumInformationRate(MIR)Up(sector‐wide)
• MaximumInformationRate(MIR)Down(sector‐wide)
• QoSConfigurationqueues(foruplinkandagainfordownlink):
•RealTime(anditsStrictWeightpercentage,MIRandTTL(Time‐to‐Live)
•NearReal‐Time
• ControlledLoad
•BestEffort
• VoIPqueue,ifapplicable
(Formoredetailsontheseparameters,seeQualityofServiceonpage 10‐1)
PrepareFilesfortheRADIUSSer ver
PreparetwofilesfortheRADIUSserver:DataDictionarysupplement,andUsersdefinitions.
» DataDictionarysupplement:
ThisisasupplementtothestandardRADIUSDataDictionary.Thisfiledefinestheattri‐
butesthatareusedbytheRADIUSserverasconfigurationpar ametersfortheHSUs.Add
thistexttotheendofthestandardRADIUSDataDictionary.Anexamplesupplement
looksasfollows:
#vendor id
VENDOR RADWIN 4458
BEGIN-VENDORRADWIN
#Service category to translate between the number and its name
ATTRIBUTE RADWIN_ServiceCategory1integer
VALUE RADWIN_ServiceCategory Residential1 1
VALUE RADWIN_ServiceCategory Residential2 2
VALUE RADWIN_ServiceCategory Residential3 3
VALUE RADWIN_ServiceCategory Residential4 4
VALUE RADWIN_ServiceCategory Business1 5
VALUE RADWIN_ServiceCategory Business2 6
VALUE RADWIN_ServiceCategory Business3 7
VALUE RADWIN_ServiceCategory Business4 8

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
