RADWIN5000ConfigurationGuide Release4.9.17 4‐42
RADIUS ManagingtheSector
EditServerParameters .ClickthisbuttontoopentheRADIUSserver
parametersdialogbox:
IPAddress:EntertheIPAddressoftheRADIUSserverhere
Port:EnterthecommunicationporttowhichtheHBSconnects(usually1812)
NumberofRetries:Ifthefirstat temptatestablishingaconnectionwiththe
RADIUSserverwasunsuccessful,carryoutthisnumberofretriesbefore
movingontothenextavailableRADIUSserver.
Timeout:IfthereisnoresponsefromtheRADIUSserverafterthismany
seconds,disconnect.Amessagewi ll appearindicatingthissituation.
ClearServerConfiguration .ClickthisbuttontoremovethespecificRADIUS
serverfromthelist.
CheckServerConnectivity .Clickthisbuttontotesttheconnectivityofthe
specificRADIUSserver.ItsstatuswillchangetoTesting,andiftheconnectionis
successful,willfurtherchangetoConnected.
AnytimeyouclosetheRADIUStab,youwillneedtoclicktheCheckServer
Connectivitybuttonagaintore‐establishconnectivity.

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
