Rational SCC Series

103
SCC
Edition 10-2008a
System Error Logger (Indication of the last 10 Service-failures with the appropriate values at the mo-
ment the failure occurred)
1: „2006-07-25 10:50:54, B1: 28, B2: 28, B6: 30, B5: 253, M1 set: 0, M1 actual: 0, M2 set: 0, M2
actual: 0, Mode: 1, Humidity %: 4, Hot air %: 0, Steam %: 0, Y2: 0, Y1: 0, S2: 1, M4: 0, EC:
00002001 Service 31: 0, Service 32: 0, Service 34: 0, Service xx: 0“
SERVICE 10
2: EGE 1005 ( Wildcards from 1-10 for additional Service failures. EGE 1005 is indicated in case
there was no failure)
Example under item 1:
Service 10: Actual failure (= SC-Pump without function)
„2006-07-25 10:50:54: Failure is occurred at 25.07.2006 at 10:50:54 hour
B1 = 28°, B2 = 28°, B6 = 35°, B5 = 253°, Temperature at sensors
M1 actual:0 and M2 actual:0 Motor was not running
(Indication 0, otherwise actual REV‘S are shown)
Mode: 1 No mode was selected
Possible indication:
2 = Steam 30-97°C
3 = Steam 98 - 103°C
4 = Steam 104 - 130°C
5 = Hot air 30 - 100°C
6 = Hot air 101 - 300°C
7 = Combination 30 - 100°C
8 = Combination 101 - 140°C
9 = Combination 141 - 300°C
10 = not relevant
11 = not relevant
12 = COOLDOWN
humidity%: 4 actual humidity 4 %;
Hot air %: 0 hot air heating switched off (possible indication 0/50/100)
Steam %: 0 steam heating switched off (possible indication 0/50/100)
Y2: 0
Solenoid valve quenching not active (possible indication 0 or 1)
Y1: 0 Solenoid valve filling steam generator not active
(possible indication 0 or 1)
S2: 1
Level electrode has contact with water (possible indication 0 or 1)
M4: 0 SC-Pump not active (possible indication 0 or 1)
EC: 00002001 no relevant information
Service 31: 0, Service 32: 0, Service 34: 0:
This failure code will always be shown. If no failure has occurred then the failure code followed by
„0“ is shown. If a failure has occurred it will be shown, like all other failures, in the error history. In this
case instead of „0“ the corresponding code is shown, e. g.:
Service 31 Info 10 (pls refer to detailed service error list)
Error 31:0 is not shown anymore since Software SCC 03-01-03.
