Rational SCC Series User Manual

109
SCC
Edition 10-2008a
Calibration SCC
Step Unit status Error Reason
40
(max. 800 s )
Filling cabinet with steam until B2 sen-
sor reaches 80°C (176°F)
• Heating: ON
• Motor: OFF
• Humidity  ap: Closed
11
71
No steam heating
Max time of 4x800sec excee-
ded
In case of „11“ check: Steam elements, SSR, Quenching sensor
50
(40 sek)
Stand-by in steam saturation
• Heating: ON
• Motor: ON (lowest speed)
• Humidity  ap: Closed
---
60
(min: 4x20 s;
max: 4x180 s)
Controlling with all 4 fan speeds:
• Steam Heating: ON 50%
• Motor: ON
• Humidity  ap: Closed
20
71
Value out of
allowable range;
Max time of 4x180sec excee-
ded
In case of „20“ check: In diagnostic mode: P1, B4, rpm
70
(4x 30 s )
Measuring at all 4 fan speeds:
Calibration value: Steam
• Heating: ON 50%
• Motor: ON
• Humidity  ap: Closed
60 Calibration value not in ex-
pected range (logic)
In case of „20“ check:
In diagnostic mode: P1, B4, rpm
Step 60 and 70 will run 1x for each rpm setting!
