Rational SCC Series

Edition 10-2008a
189
76-00014
0
Version
MODUL 6 Garraumbeleuchtung, Summer,
Zentrales Einstellrad, EEPROM
201 - 202
Erstellt von Created by Datum Date Blatt Page
PA
6
30.04.2004
A1
I/O-PCB
W11
BN BU
X13
11
X49
1
H1
Garraumbeleuchtung
Interior cabinetlight
22 2
A2
Operator PCB
W9
WH WH
X8
11
X47
1
T2
Summer
Buzzer
22
2
X9
11
S6
Zentrales Einstellrad
Central dial
22 33 44 55 66
X50
EEPROM
11 22
EEPROM
33 44
H2
0
9876543210
