Rational SCC Series

Edition 10-2008a
188
76-00014
0
Version
MODUL 4 Wasser
Water, Drain, CleanJet
Erstellt von Created by Datum Date Blatt Page
PA
4
30.04.2004
A1 I/O-PCB
W2
WH
PE
WH
X15
22
X28
11
S11
CDS-Sensor
CDS-sensor
GND
IN
Signal
HALL
11 22
33 33
W6
HWHWHWHW
X25
11
X45
1
S12
Endschalter Verschlußmotor
End switch drain valve
22 2
33 44 55 66 77
3
M7
Verschlußmotor
Drain valve
M
-+
88 4
W3
WH
BU
WH
BU
WH
BU
Y1
Magnetventil-Füllen
Solenoid valve lling
A1 A2
X19
44
X30
11
11 22
Y2
Magnetventil-Ablöschung
Solenoid valv e guenchi ng system
A1 A2
55 33
22 44
Y3
Magnetventil-Beschwadung
Solenoid valve moistening
A1 A2
66 55
33 66
M4
SC-Pumpe
SC-pump
M
~
W4
WH
BU
WH
BU
X18
11
X31
11
22 22
44
44
M6
Kondensator C1 2,5μF
Capacitor
Umwälzpumpe Reinigung
Cleanjet circulation pump
M
C1
.
~
33 33
0
9876543210
