Rational SCC Series

Edition 10-2008a
187
Version
MODUL 4 Wasser
Water, Drain, CleanJet
Erstellt von Created by Datum Date Blatt Page
schd
4
25.06.2008
A1
I/O-PCB
X15
22
X28
11
S11
CDS-Sensor
CDS-sensor
GND
IN
Signal
HA LL
11 22
33
33
X25
11
X45
1
S12
Endschalter Verschlußmotor
End switch drain valve
22 2
33 44 55 66 77
3
M7
Verschlußmotor
Drain valve
M
-
+
88
4
W28
HWRORB
BU
WH ;WH
BU
WH
BU
WH
BU
Y1
Magnetventil-Füllen
Solenoid valve lling
A1 A2
X19
44
X30
11
11 22
Y2
Magnetventil-Ablöschung
Solenoid valve guenching system
A1 A2
55 33
22 44
Y3
Magnetventil-Beschwadung
Solenoid valve moistening
A1 A2
66 55
33 66
M12
Pumpe Pegemittel
Care Pump
M
~
W30
BR
BU
X75
11
X77
11
22 22
Y4
Magnetventil Pegemittel
Solenoid valve Care
A1 A2
33
X76
11
44
22
X17
11 22 33
M4
SC-Pumpe
SC-pump
M
~
X18
11
X31
11
22 22
44 44
M6
Kondensator C1 2,5μF
Capacitor
Umwälzpumpe Reinigung
Cleanjet circulation pump
M
C1
.
~
33 33
0
9876543210
Care Brücke
Care link
ab / from / de 10-2008
