Rational SCC Series User Manual

30
CM
Edition 10-2008
Service Level: F -- Function Test
Note: In function test components are NOT protected against overload!
Set DIP switch 3 to „ON“ position!
Function Connection
I/O pcb
Cabinet
display
Time
Display
Comment
Gas blower Steam
MIN rpm
BUS actual rpm Set CO
2
Check CO
2
value
Gas blower Steam
Start rpm
BUS actual rpm
Gas blower Steam
MAX rpm
BUS actual rpm Set CO
2
Adjust CO
2
value with
CO
2
screw
Gas blower Hot air top
MIN rpm
BUS actual rpm Set CO
2
Check CO
2
value
Gas blower Hot air top
Start rpm
BUS actual rpm
Gas blower Hot air top
MAX rpm
BUS actual rpm Set CO
2
Adjust CO
2
value with
CO
2
screw
Gas blower Hot air bottom
MIN rpm
BUS actual rpm Set CO
2
Check CO
2
value
Gas blower Hot air bottom
Start rpm
BUS actual rpm
Gas blower Hot air bottom
MAX rpm
BUS actual rpm Set CO
2
Adjust CO
2
value with
CO
2
screw
