Rational SCC Series User Manual

52
SCC
Edition 10-2008a
Sequence Cleanjet+Care Process: 1. step - Cleaning cabinet; example: SCC 61, Index G Prepare Cleanjet Cleanjet Phase 1 Cleanjet Phase 2 Prepare for care phase
SC Pump M4 1 0 Solenoid Y1  lling steam generator 1 Function test (CDS) 0 Solenoid Y3 moistening 1
Function test (CDS) 0 Solenoid Y4 Care 1 Function test (CDS) 0 Drain valve M7 1 0 Solenoid Y2 quenching Filling quenching box (pre-cleaning) 1 Level control by prm signal M1 0 Solenoid Y3 moistening 1 Filling quenching box Phase 2 0 level control by CDS Cleanjet pump M6 1 1. Phase Cleanjet 0 2. Phase Cleanjet Steam heating Pre heating steam generator Steam Cabinet 90°C
