16 - DIAGNOSTIC
Clima Status
Cal. Speed 1 Error
xxx rpm ---
Dry Wet Combi
xxxx xxxx xxxx
Diagnostic mode SCC
16.1 - DIAGNOSTIC
Cal.Geodat
Auto. Calibration
-1.0000 1.0000
m.val a.val
ON
17 - DIAGNOSTIC
Clima Motor
M3 0 - 1
S4 1 - 0
18 - DIAGNOSTIC
Hot Air
50%
19 - DIAGNOSTIC
Steam
100%
- Display of calibration values relative to the different motor
speeds and unit size;
- Normal values between 72000-130000
Automatic Humidity calibration
AFTER manual calibration this feature is set to „OFF“.
Do not reset to „ON“ after manual calibration.
When „ON“ Autocalibration will be done when cabinet is cold
and the steam generator is preheating;
1.0000 is only shown when autocalibration is „OFF“
M3: Motor ClimaPlus Flap
S4: Micro switch ClimaPlus  ap
No steam production, when S4 is „0“ => open!
possible values:
0: hot air heating off
50%: hot air heating 50%
100%: hot air heating 100%
possible values:
0: steam heating off
50%: steam heating 50%
100%: steam heating 100%
