Diagnostic mode SCC
Test
20 - DIAGNOSTIC
SC Automatic
53min
45sec 60min
Window 3:
- 53min since last SC -automatic
- Pressing Test => time will be set to set time plus 1 minute
Window 4:
- 45sec: Preset SC-duration (20-90sec)
- 60min: Preset SC-time (20-90min)
Calccheck 3,2l: Release volume for indication CalcCheck
Fill 3,6l: actual measured water content steam generator
Norm 4,2l: Volume when steam generator is new and clean
M6: CleanJet Pump
Y2: solenoid valve quenching
M7: Drain valve motor
S12: Micro switch drain valve
M12 Care motor
Y4 Care Solenoid
Display only from Software SCC 04-01-02
21 - DIAGNOSTIC
Volume
Calc- 3,2L
check
Fill Norm
3,6L 4,2L
22 - DIAGNOSTIC
M6 CleanJet Pump
Y2 Quenching Sol.
M6 0 - 1
Y2 0 - 1
23 - DIAGNOSTIC
M7 Drain valve motor
S12 Micro switch
M7 0 - 1
S12 1 - 0
23.1 - DIAGNOSTIC
M12 Care motor
Y4 Care Solenoid
M12 0 - 1
Y4 1 - 0
