RED RAVEN OPERATION GUIDE

955-0127_V6.3, REV-E | 167

This appendix provides pinout information for the input/output connectors on the following expanders:

 DSMC2

™

Base Expander

 DSMC2 V-Lock I/O Expander

 DSMC2 REDVOLT Expander

 DSMC2 Jetpack Expander

 DSMC2 Jetpack-SDI Expander

NOTE: When connecting a cable to a connector, align the key and red marker on the cable connector with the

corresponding key and marker on the device connection.

NOTE: Connector diagram images are for reference only. Diagrams are not to scale.

INPUT/OUTPUT

CONNECTORS
