COPYRIGHT © 2016 RED.COM, INC
RED RAVEN OPERATION GUIDE
955-0127_V6.3, REV-E | 188
LENSES
This section describes lenses and lens operations for the camera system.
WARNING: All lenses are hot swappable.
LENS WEIGHT AND LENS SUPPORT
Use a lens support system when mounting heavy or long lenses to your camera.
When mounting a heavy or long lens, ensure that the full weight of the lens is never directly on the camera or
lens mount. Mount the lens to the support system first, and then carefully mount the lens to the camera.
WARNING: Failure to use lens supports appropriate for the lens and camera setup may lead to damage of the
camera and lens mount. Any damage caused by not using a lens support system will not be covered under
warranty.
CANON EF LENSES
This section describes the appropriate method for attaching and detaching Canon
®
EF lenses. For more
information, refer to the original manufacturer’s instructions. This section also lists lenses supported by the
DSMC
®
Canon EF Mount.
WARNING: ALWAYS protect your equipment, when it is not in use, by replacing lens caps and mount caps.
ATTACH CANON EF LENSES
1. Rotate the secondary locking ring counter-clockwise to disengage.
2. Press the lens release button and rotate the lens cap counter-clockwise to remove the camera mount cap.
3. Remove the rear lens cap.
4. Align the red dot on the lens with the red dot on the DSMC Canon Mount and position the lens in the mount.
5. Turn the lens clockwise until it clicks into place.
6. Rotate the secondary locking ring clockwise to engage.
DETACH CANON EF LENSES
1. Rotate the secondary locking ring counter-clockwise to disengage.
2. Press and hold the lens release button. While holding the lens release button, turn the lens counterclockwise
until it stops and remove it from the camera mount.
3. Replace the rear lens cap and camera mount cap when the lens is not in use.
C
LENSES
