COPYRIGHT © 2016 RED.COM, INC
RED RAVEN OPERATION GUIDE
955-0127_V6.3, REV-E | 36
INSTALL THE FOCUS HOOK
For more information on the focus hook storage location and mounting point, go to “BRAIN Connectors, Focus
Hook, and Back Focus” on page 14.
REQUIRED TOOLS: 1.5 mm hex key, slotted screwdriver
1. Remove the M3x0.5 x 3 mm set screw from the focus hook mounting point on the media bay using a
1.5 mm hex key.
NOTE: Store the screw in a safe location, or install it in the focus hook storage location after you remove
the focus hook in Step 2.
2. Remove the focus hook from the focus hook storage location on the media bay using a slotted screwdriver.
3. Tighten the focus hook into the focus hook mounting point on the media bay using a slotted screwdriver.
WARNING: DO NOT OVERTIGHTEN.
USE A TRIPOD OR MONOPOD
This section describes the camera mounting points and mounting equipment for use with a tripod or monopod.
The camera is equipped with two (2) 3/8-16 mounting holes and one (1) 1/4-20 mounting hole on the bottom
of the camera. These mounting points are designed for use with a variety of mounting plates and hardware, to
support tripods and other support systems.
WARNING: Ensure that the tripod, monopod, or support system is designed and rated to handle the weight of
your camera configuration. RED is not responsible for any damage caused by using a tripod, monopod, mount,
or support system that does not provide sufficient support.
WARNING: DO NOT use excessive force to mount a support accessory, as this may damage the screw threading.
RED offers the following products for use with tripods and other support systems:
ITEM PART NUMBER
Mounting Plate (DSMC) 790-0094
DSMC Quick Release Platform Pack 790-0183
Quick Release Platform Pack (Bolt-On) 790-0078
Quick Release Platform (Dovetail) 790-0079
Quick Release Platform (Mini) 790-0390
Dovetail Mounting Plate (Long) 790-0083
Dovetail Mounting Plate (Short) 790-0084
For more information, visit the RED store at www.red.com/store.
