RED Raven User Manual

COPYRIGHT © 2016 RED.COM, INC
RED RAVEN OPERATION GUIDE
955-0127_V6.3, REV-E | 159
RED RAVEN
RED RAVEN TECHNICAL SPECIFICATIONS
SPECIFICATION DESCRIPTION
Sensor Type RED DRAGON
®
9.9 Megapixel CMOS
Effective Pixels 4608 x 2160
Sensor Size 23.0 mm x 10.8 mm (Diagonal: 25.5 mm)
Dynamic Range 16.5+ stops
Signal-to-Noise Ratio 80 dB
Max Data Rates Up to 140 MB/s using RED MINI-MAG
®
Max Frame Rates
1
120 fps at 4.5K Full Frame (4608 x 2160), 120 fps at 4.5K 2.4:1 (4608 x 1944)
120 fps at 4K Full Frame (4096 x 2160), 150 fps at 4K 2.4:1 (4096 x 1728)
150 fps at 3K Full Frame (3072 x 1620), 200 fps at 3K 2.4:1 (3072 x 1296)
240 fps at 2K Full Frame (2048 x 1080), 300 fps at 2K 2.4:1 (2048 x 864)
Playback Frame Rates
(Project Time Base)
23.98, 24, 25, 29.97, 47.95, 48, 50, 59.94, 60 fps, all resolutions
REDCODE
®
Settings
(Range from 2:1 up to 22:1)
1
To see all of the maximum available REDCODE values, see the DSMC Media
Operation Guide at www.red.com/downloads
REDCODE RAW
Acquisition Formats
Go to “RED RAVEN Formats” on page 76 for a full list
Apple
®
ProRes 422 HQ, 422 and 422 LT at 2K (2048 × 1080) up to 60 fps
Avid
®
Codecs DNxHD LB (1920 × 1080) 8-bit up to 60 fps
Typical Max Recording
Time Using RED MINI-MAG
120GB
2
4.5K Full Frame (4608 × 2160) at 24 fps and 11:1 REDCODE: 57 minutes
4.5K Full Frame (4608 × 2160) at 60 fps and 14:1 REDCODE: 29 minutes
4.5K 2.4:1 (4608 x 1944) at 120 fps and 15:1 REDCODE: 17 minutes
Construction Aluminum Alloy
Weight 3.5 lbs (BRAIN
®
with Integrated Media Bay and Canon
®
Lens Mount)
Operating Temperature 0˚C to 40˚C (32˚F to 104˚F)
Storage Temperature –20˚C to 50˚C (–4˚F to 122˚F)
Relative Humidity 0% to 85% non-condensing
A
TECHNICAL
SPECIFICATIONS

RED Raven Specifications

General

Sensor Type	RED Dragon
Dynamic Range	16.5+ stops
Media Type	RED MINI-MAG
Weight	3.5 lbs (body only)
Resolution	4608 x 2160
Frame Rates	up to 120 fps at 4.5K
Lens Mount	Canon EF
Recording Format	REDCODE RAW
ISO Range	ISO 800 native
