FORMAT
Use the Format menu to select the resolutionand aspect ratio. The available aspect ratios are determined by
the selected resolution.
After selecting format settings, select Set Format.
When you lower the resolution on a camera, only a portion of the sensor is used. The camera does not
downscale from full frame when recording RAW.
RED RAVEN FORMATS
The table below describes the formats for each of the RED RAVEN™.
RESOLUTION DIMENSIONS (PIXELS) DIMENSIONS (MM)
WIDTH HEIGHT WIDTH HEIGHT DIAGONAL
4.5K 2.1:1 4608 2160 23.04 10.80 25.45
4.5K 2.4:1 (WS) 4608 1944 23.04 9.72 25.01
4K FF 4096 2160 20.48 10.80 23.15
4K 2:1 4096 2048 20.48 10.24 22.90
4K 2.4:1 (WS) 4096 1728 20.48 8.64 22.23
4K 16:9 (HD) 3840 2160 19.20 10.80 22.03
3.5K FF 3584 1876 17.92 9.38 20.23
3.5K 2:1 3584 1792 17.92 8.96 20.04
3.5K 2.4:1 (WS) 3584 1512 17.92 7.56 19.45
3.5K 16:9 (HD) 3456 1944 17.28 9.72 19.83
3K FF 3072 1620 15.36 8.10 17.36
3K 2:1 3072 1536 15.36 7.68 17.17
3K 2.4:1 (WS) 3072 1296 15.36 6.48 16.67
3K 16:9 (HD) 2880 1620 14.40 8.10 16.52
3K 3:2 2880 1920 14.40 9.60 17.31
2.5K FF 2560 1340 12.80 6.70 14.45
2.5K 2.1 2560 1280 12.80 6.40 14.31
2.5K 2.4:1 (WS) 2560 1080 12.80 5.40 13.89
2.5K 16:9 (HD) 2304 1296 11.52 6.48 13.22
2.5K 3:2 2400 1600 12.00 8.00 14.42
2K FF 2048 1080 10.24 5.40 11.58
2K 2:1 2048 1024 10.24 5.12 11.45
2K 2.4:1 (WS) 2048 864 10.24 4.32 11.11
2K 16:9 (HD) 1920 1080 9.60 5.40 11.01
2K 3:2 1920 1280 9.60 6.40 11.54
