RED Raven User Manual

COPYRIGHT © 2016 RED.COM, INC
RED RAVEN OPERATION GUIDE
955-0127_V6.3, REV-E | 197
ITEM KEY FUNCTION
Camera BRAIN
®
Record Full Press Record: Toggle
GPI In High Record: Start
GPI In Low Record: Stop
Media Bay (Side SSD) Record Full Press Record: Toggle/Multi-Shot Start
Record Full Release Record: Multi-Shot Stop
Record Half Press AF: Start
User 1+2 Press Eject Media
LCD (Primary and
Secondary)
Up Press Br. Up (Increase Brightness)
Down Press Br. Down (Decrease Brightness)
User 1 Press Magnify: Toggle
User 2 Press Exposure Check: Toggle
User 1+2 Press LCD: Toggle Lock
EVF (Primary and
Secondary)
User 1 Press Magnify: Toggle
User 2 Press Exposure Check: Toggle
DSMC2
™
Sidekick User A Press AF Mode: Cycle
User B Press WB: Auto Calc
User C Press Magnify: Toggle
User D Press Exposure Check: Toggle
User A+D Press SM: Toggle Key Lock
Nav Menu Press Navigation: Menu
Nav North Press Navigation: Up
Nav South Press Navigation: Down
Nav East Press Navigation: Right
Nav West Press Navigation: Left
Nav Enter Press Navigation: Select
Rotary CW Navigation: CW
Rotary CCW Navigation: CCW
DSMC2 Top Handle Record Full Press Record: Toggle/Multi-Shot Start
Record Full Release Record: Multi-Shot Stop
D
DEFAULT KEY
FUNCTIONS

RED Raven Specifications

General

Sensor Type	RED Dragon
Dynamic Range	16.5+ stops
Media Type	RED MINI-MAG
Weight	3.5 lbs (body only)
Resolution	4608 x 2160
Frame Rates	up to 120 fps at 4.5K
Lens Mount	Canon EF
Recording Format	REDCODE RAW
ISO Range	ISO 800 native
