RED Raven User Manual

COPYRIGHT © 2016 RED.COM, INC
RED RAVEN OPERATION GUIDE
955-0127_V6.3, REV-E | 24
RED BATTERIES AND CHARGERS
RED offers the following batteries and chargers:
ITEM PART NUMBER
REDVOLT XL 740-0021
REDVOLT Charger (Quad) 740-0015
For more information, see the DSMC Power Operation Guide, available at www.red.com/downloads.
DISPLAYS AND ELECTRONIC VIEWFINDERS
RED offers the following displays and electronic viewfinders (EVFs):
NOTE: RED offers multiple mounting solutions for each camera type.
ITEM RESOLUTION TILT
(APPROXIMATE)
SWIVEL
(APPROXIMATE)
PART
NUMBER
DSMC2 RED Touch 7.0" LCD
(Woven CF)
1
1920 x 1136 Total: 180°
Forward: 90°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0018
DSMC2 RED Touch 7.0" LCD
(Aluminum)
1
1920 x 1136 Total: 180°
Forward: 90°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0024
DSMC2 RED Touch 4.7" LCD
1
1280 x 720 Total: 240°
Forward: 90°
Backward: 150°
No swivel 730-0019
RED Touch 5.0" LCD
2
800 x 400 Total: 270°
Forward: 180°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0008
RED Touch 7.0" LCD
2
1920 x 1136 Total: 180°
Forward: 90°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0007
RED Touch 9.0" LCD
2
1280 x 768 Total: 270°
Forward: 180°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0011
RED PRO LCD 7"
2
1024 x 600 No tilt No swivel 730-0009
DSMC2 RED EVF (OLED)
2
1920 x 1080 N/A N/A 730-0021
BOMB EVF
®
(LCOS)
2
1280 x 784 N/A N/A 730-0004
BOMB EVF (OLED)
2
1280 x 1024 N/A N/A 730-0010
1. Using this display with an EPIC or SCARLET camera requires a DSMC2 LEMO Adaptor B.
2. Using this display with a DSMC2 camera requires a DSMC2 LEMO Adaptor A.
For a full list of LCD and EVF user keys and default actions, go to “Default Key Functions” on page 197.

RED Raven Specifications

General

Sensor Type	RED Dragon
Dynamic Range	16.5+ stops
Media Type	RED MINI-MAG
Weight	3.5 lbs (body only)
Resolution	4608 x 2160
Frame Rates	up to 120 fps at 4.5K
Lens Mount	Canon EF
Recording Format	REDCODE RAW
ISO Range	ISO 800 native
