Reflex Servitec 35 Original Operating Manual

Technical data
26 — English
Vacuum spray degassing — 24.04.2020 - Rev. A
Basic degassing equipment:
• Control of the Servitec.
• "DV" degassing valve, box-packaged.
• Plastic sleeve with operating manual and electric wiring diagram (attached
to the Servitec).
The Servitec is pre-assembled and shipped on a pallet.
4.5 Optional equipment and accessories
The following optional equipment and accessories are available for this device:
• Fillsoft/Fillsoft zero for softening/desalination of the make-up water from
the potable water supply system. Replacement of the softening and
desalination cartridges.
• Fillset for make-up with water
– Fillset with integrated backflow preventer, water meter, dirt trap,
and shut-ff for the "WC" make-up line
• Fillset Impulse with FQIR+ contact water meter for make-up with water.
– If the Fillset Impulse is installed, you can regulate the entire make-up
quantity and the soft water capacity of Fillsoft softening systems. The
operational reliability of the device is assured and prevents
automatic make-up during major water loss or small leaks.
• Fillset Compact for make-up
– Fillset Compact with integrated system separator, dirt trap, and shut-
off for the "WC" make-up line.
• Fillguard for conductivity monitoring
– If the Fillguard is fitted, the capacity of the Fillsoft Zero desalination
cartridge can be monitored based on the conductivity.
• Enhancements for the device controller.
– Various controller information can be queried via the RS-485
interface and it can also be used to communicate with control
centres or other devices, see chapter 6.5.2.1 "Connecting the RS-485
interface" on page 30 .
• Bus modules for the communication with control centres.
• Profibus-DP.
• Ethernet.
• I/O module for standard communication.
• Modbus RTU
• Control Remote
• Gas discharge measurement for optimised degassing operation.

Note!
Separate operating manuals are supplied with accessories.
5 Technical data

Note!
The following values apply for all systems:
– Permissible operating temperature of the device:
– Permissible inlet pressure for make-up:
– Make-up capacity:
– Separation level, dissolved gases:
– Separation level, free gases:
– Degree of protection:
90 °C
1.3 bar – 6 bar
Up to 0.55 m³/h
≤ 90 %
100 %
IP 54
5.1 El ectrical system
Ty pe
Power output
(kW)
Power supply
(V / Hz/ A)
Fusing
(internal)
(A)
Number of RS-485
interfaces
I/O module
Control Unit
(V, A)
Noise level
(dB)
35
0.7
230 / 50
10
1
No
230, 4
55
60
1.1
230 / 50
10
1
No
230, 4
55
75
1.1
230 / 50
10
1
No
230, 4
55
95
1.1
230 / 50
10
1
No
230, 4
55
5.2 Dimensions and connections
Ty pe
Weight
(kg)
Height
(mm)
Width
(mm)
Depth
(mm)
Servitec input
connections (system
and make-up)
Servitec output
connection
35
42
1030
620
440
Internal thread ½ "
Internal thread 1 "
60
40
1215
685
440
Internal thread ½ "
Internal thread 1 "
75
39
1215
600
525
Internal thread ½ "
Internal thread 1 "
95
40
1215
600
525
Internal thread ½ "
Internal thread 1 "
5.3 Operation
Ty pe
Sy stem volume
(100% water)
(m³)
Sy stem volume
(50% water)
(m³)
Working pressure
(bar)
Permissible operating
gauge pressure
(bar)
Setpoint overflow
valve
(bar)
Operating
temperature
(°C)
35
up to 220
up to 50
0.5 – 2.5
8
–
>0 – 90
60
up to 220
up to 50
0.5 – 4.5
8
–
>0 – 90
75
up to 220
up to 50
1.3 – 5.4
10
–
>0 – 90
95
up to 220
up to 50
1.3 – 7.2
10
–
>0 – 90
