RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 174

Sep 22, 2011

Figure 4-6. Block Diagram of P05 and P07

P05 to P07

PORT

P-ch

PU0

PM0

PM05 to PM07

PU05 to PU07

Output latch

(P05 to P07)

Selector

Internal bus

P0: Port register 0

PU0: Pull-up resistor option register 0

PM0: Port mode register 0

RD: Read signal

WR××: Write signal
