RL78/G13
CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00
188
Sep 22, 2011
For example, figures 4-16 to 4-19 show block
diagrams of port 3 for 128-pin products when PIOR =
00H.
Figure 4-16. Blo
ck Diagram of P30
P30/RTC1HZ/INTP3
WR
PU
RD
WR
PORT
WR
PM
PU30
PM30
EV
DD
P-ch
PU3
PM3
P3
Output latch
(P30)
Selector
Alternate
function
Alternate
function
Internal bus
P3:
Port register 3
PU3:
Pull-u
p resistor option register 3
PM3:
Port mode register 3
RD: Read
sign
al
WR
××
: Write
signal
<R>
206
