RL78/G13
CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00
215
Sep 22, 2011
Figure 4-36. Blo
ck Diagram of P72
P72/KR2/SO21
WR
PU
RD
WR
PORT
WR
PM
PU72
PM72
EV
DD
P-ch
PU7
PM7
P7
Output latch
(P72)
Selector
Alternate
function
Alternate
function
Internal bus
P7:
Port register 7
PU7:
Pull-u
p resistor option register 7
PM7:
Port mode register 7
RD: Read
sign
al
WR
××
: Write
signal
233
