RL78/G13 CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00 216
Sep 22, 2011
Figure 4-37. Block Diagram of P73, P75 to P77
P73/KR3,
P75/KR5/INTP9 to
P77/KR7/INTP11
WR
PU
RD
WR
PORT
WRPM
PU73, PU75 to PU77
PM73, PM75 to PM77
EVDD
P-ch
PU7
PM7
P7
Output latch
(P73, P75 to P77)
Selector
Alternate
function
Internal bus
P7: Port register 7
PU7: Pull-up resistor option register 7
PM7: Port mode register 7
RD: Read signal
WR××: Write signal
