RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 277

Sep 22, 2011

Table 4-23. Settings of Port Mode Register, and Output Latch When Using Alternate Function (5/5)

Alternate Function Pin Name

Function Name I/O

PIOR× POM××

PMC×× PM×× P××

Input

× − −

SCK11

Output

−

0 1

P95

SCL11 Output

× − −

0 1

SI11 Input

× × −

P96

SDA11 I/O

−

0 1

P97 SO11 Output

× − −

0 1

P100 ANI20

Note 1

Input

−

1 1

TI06 Input 0

− −

P102

TO06 Output 0

− −

0 0

TI14 to TI17 Input

× − −

P103 to P106

TO14 to TO17 Output

× − −

0 0

P110, P111

(INTP10), (INTP11) Input 1

− −

P115 to P117

ANI26 to ANI24

Note 1

Input

−

1 1

P120 ANI19

Note 1

Input

−

1 1

P137

INTP0 Input

× − − − ×

PCLBUZ0 Output 0

−

0 0 P140

INTP6 Input 0

− −

PCLBUZ1 Output 0

−

0 0 P141

INTP7 Input 0

− −

Input

× × −

SCK30

Output

0/1

−

0 1

P142

SCL30 Output

0/1

−

0 1

RxD3 Input

× × −

SI30 Input

× × −

P143

SDA30 I/O

−

0 1

TxD3 Output

0/1

−

0 1

P144

SO30 Output

0/1

−

0 1

TI07 Input 0

− −

P145

TO07 Output 0

−

0 0

P146

(INTP4)

Input

−

P147 ANI18

Note 1

Input

× −

1 1

P150 to P156

Note 2

ANI8 to ANI14

Note 2

Input

× − −

Remarks 1. ×: don’t care

PIOR×: Peripheral I/O redirection register

POM××: Port output mode register

PMC××: Port mode control register

PM××: Port mode register

P××: Port output latch

2. The relationship between pins and their alternate functions shown in this table indicates the relationship

when a 128-pin product is used. In other products, alternate functions might be assigned to different

pins, but even in this case, the PIOR×, POM××, PMCxx, PMxx, and Pxx set in the same way.

3. Functions in parentheses in the above table can be assigned via settings in the peripheral I/O

redirection register (PIOR).
