Figure 6-39. Example of Set Contents of Registers During Operation as Interval Timer/Square Wave Output (2/2)
(d) Timer output level register m (TOLm)
Bit n
TOLm
TOLmn
0
0: Cleared to 0 when TOMmn = 0 (master channel output mode)
(e) Timer output mode register m (TOMm)
Bit n
TOMm
TOMmn
0
0: Sets master channel output mode.
Remark m: Unit number (m = 0, 1), n: Channel number (n = 0 to 7)
