RL78/G13 CHAPTER 11 A/D CONVERTER
R01UH0146EJ0100 Rev.1.00 498
Sep 22, 2011
(8) Conversion result comparison upper limit setting register (ADUL)
This register is used to specify the setting for checking the upper limit of the A/D conversion results.
The A/D conversion results and ADUL register value are compared, and interrupt signal (INTAD) generation is
controlled in the range specified for the ADRCK bit of A/D converter mode register 2 (ADM2) (shown in Figure 11-8).
The ADUL register can be set by an 8-bit memory manipulation instruction.
Reset signal generation sets this register to FFH.
Caution When 10-bit resolution A/D conversion is selected, the higher eight bits of the 10-bit A/D conversion
result register (ADCR) are compared with the ADUL register.
Figure 11-12. Format of Conversion Result Comparison Upper Limit Setting Register (ADUL)
Address: F0011H After reset: FFH R/W
Symbol 7 6 5 4 3 2 1 0
ADUL ADUL7 ADUL6 ADUL5 ADUL4 ADUL3 ADUL2 ADUL1 ADUL0
(9) Conversion result comparison lower limit setting register (ADLL)
This register is used to specify the setting for checking the lower limit of the A/D conversion results.
The A/D conversion results and ADLL register value are compared, and interrupt signal (INTAD) generation is
controlled in the range specified for the ADRCK bit of A/D converter mode register 2 (ADM2) (shown in Figure 11-8).
The ADLL register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 11-13. Format of Conversion Result Comparison Lower Limit Setting Register (ADLL)
Address: F0012H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
ADLL ADLL7 ADLL6 ADLL5 ADLL4 ADLL3 ADLL2 ADLL1 ADLL0
Caution When 10-bit resolution A/D conversion is selected, the higher eight bits of the 10-bit A/D conversion
result register (ADCR) are compared with the ADLL register.
