RL78/G13 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0146EJ0100 Rev.1.00 583

Sep 22, 2011

(3) Processing flow (in single-transmission mode)

Figure 12-30. Timing Chart of Master Transmission (in Single-Transmission Mode)

(Type 1: DAPmn = 0, CKPmn = 0)

SSmn

STmn

SEmn

SDRmn

SCKp pin

SOp pin

Shift

INTCSIp

TSFmn

Data transmission (8-bit length)

Transmit data 3

Transmit data 2

Transmit data 1

Transmit data 2

Transmit data 3

Shift operation

Remark m: Unit number (m = 0, 1), n: Channel number (n = 0 to 3), p: CSI number (p = 00, 01, 10, 11, 20, 21, 30,

31), mn = 00 to 03, 10 to 13
