SERVICE PROGRAM MODE TABLES 20 June 2005
5-6
1106 Fusing Temperature Display
1106 1 Roller Center Displays the fusing temperature for the center of the hot roller.
1106 2 Roller Ends Displays the fusing temperature for the ends of the hot roller.
1106 3 I/O Board Temp.
at Power On
Displays in the internal temperature of the machine when it
was powered on.
Fusing Nip Band Check 1109*
Checks the fusing nip band.
[0=Off, 1=On]
Paper Reverse Timing (Duplex) [+5 ~ –5 / 0 mm / 1 mm step]
1111*
Adjusts the timing for stopping the rotation of the reverse roller after the trailing
edge of the paper passes the duplex entrance sensor.
Adjust the timing if paper frequently jams at the inverter gate in the duplex unit.
Motor Speed Adjustment 1801*
Adjusts the speeds of the main motor, feed/development motor, and fusing exit
motor. Each step decreases or increases motor speed in 0.15% increments
1801 1 Main Motor [-4 ~ +4 / 0 / 0.15%]
1801 2 Feed/Development Motor [-4 ~ +4 / 0 / 0.15%]
1801 3 Fusing/Exit Motor [-4 ~ +4 / 0 / 0.15%]
