Ricoh Aficio MP 301SPF Service Manual

BICU and Controller Board
SM 4-35 D127/D128
Replacement
and
Adjustment
 When replacing the controller board, remove the NVRAMs from the board. Install the
NVRAMs to the new board.
When installing a new controller board
1. Install the NVRAM from the old controller board on a new controller board.
2. Install the new controller board in the machine.
3. Disconnect the cables of the HDD from the controller board if the HDD option has already been
installed.
 Disconnecting the cables of the HDD is very important. Otherwise, the HDD is
automatically formatted and all data in the HDD is lost due to the security limitation.
4. Reassemble the machine.
5. Turn on the main power of the machine.
 If the HDD option has not been installed, the installation procedure is completed.
 If the HDD option has already been installed, go to next step.
6. Turn off the main power of the machine, and then connect the cables of the HDD again.
 Make sure you print out the SMC reports ("SP Mode Data" and "Logging Data") before
you replace the NVRAM.
 Keep NVRAMs away from any objects that can cause static electricity. Static electricity
can damage NVRAM data.
 Make sure the NVRAM is correctly installed on the controller board.

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
