Ricoh Aficio MP 301SPF Service Manual

Controller Options
SM 2-31 D127/D128
Installation
If reception is poor, you may need to move the machine:
 Make sure that the machine is not located near an appliance or any type of equipment that
could generate a strong magnetic field.
 Position the machine as close as possible to the access point.
SP Mode Settings for IEEE 802.11a/g Wireless LAN
The following SP commands can be set for IEEE 802.11a/g
SP No. Name Function
5840 004 SSID Used to confirm the current SSID setting.
5840 006 Channel MAX
Sets the maximum range of the channel settings for
the country.
5840 007 Channel MIN
Sets the minimum range of the channel settings
allowed for your country.
5840 011 WEP Key Select Used to select the WEP key (Default: 00).
2.6.3 IEEE 1284 INSTALLATION
 Unplug the machine power cord before starting the following procedure.
Accessories
Check the accessories and their quantities against the table below.
No. Description Q'ty
1 IEEE1284 Interface Ass'y 1
2 UL Sheet 1
3 Caution Sheet 1

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
