Ricoh Aficio MP 301SPF Service Manual

Dedicated Transmission Parameters
D127/D128 5-88 SM Appendix
Switch 04 - Not used (do not change the settings)
Switch 05 - Not used (do not change the settings)
Switch 06 - Not used (do not change the settings)
Switch 07 - Not used (do not change the settings)
Switch 08 - Not used (do not change the settings)
Switch 09 - Not used (do not change the settings)
E-mail Parameters
The initial settings of the following e-mail parameters are all "0" (all parameters disabled).
Switch 00
No FUNCTION COMMENTS
0
MH Compression mode
for e-mail attachments
0: Off
1: On
Switches MH compression on and off for files
attached to e-mails for sending.
1
MR Compression mode
for e-mail attachments
0: Off
1: On
Switches MR compression on and off for files
attached to e-mails for sending.
2
MMR Compression mode
for e-mail attachments
0: Off
1: On
Switches MMR compression on and off for files
attached to e-mails for sending.
3-6 Not used Do not change these settings.

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
