Ricoh Aficio MP 301SPF Service Manual

System Service Mode
SM Appendix 3-1 D127/D128
Appendix:
SP Mode
Tables
3. APPENDIX: SP MODE TABLES
3.1 SYSTEM SERVICE MODE
3.1.1 SERVICE MODE TABLES (SYSTEM SP TABLES)
SP1-XXX (Feed)
1001* LE Registration [–9.0 to 9.0 / 0.0 / 0.1 mm/step]
1001 1 All Trays
Adjusts the leading-edge registration
(
"Adjusting Copy Image Area" in the section
"Replacement and Adjustment").
1001 2 By-pass
1001 3 Duplex
1002* S-to-S Regist [–9.0 to 9.0 / 0.0 / 0.1 mm/step]
1002 1
1st Tray
Adjusts the side-to-side registration
( "Adjusting Copy Image Area" in the section
"Replacement and Adjustment"). SP1-002-001
is applied to all trays. SP1-002-002, 003 and
005 adjusts the difference from SP1-002-001.
1002 2
2nd Tray
1002 3
3rd Tray
1002 4
By-pass
1002 5
Duplex
Adjusts the side-to-side registration of the 2nd
side in duplex copying. The 1st side is adjusted
by SP1-002-001 through 005.
1003* Paper Feed Timing
Adjusts the amount of paper buckle on the
registration roller.
1003 1 1st tray
[-5 to 5 / 0 / 1 mm/step]
1003 2 Bank Trays
1003 3 By-pass
1003 4 Duplex

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
