Ricoh Aficio MP 301SPF Service Manual

Specifications
SM Appendix 1-9 D127/D128
Appendix:
Specifications
IP-FAX Specifications
Network:
Local Area Network
Ethernet/10base-T, 100base-TX
IEEE1394 (IP over 1394)
IEEE802.11b (wireless LAN)
Scan line density:
8 x 3.85 lines/mm, 200 x 100dpi (standard characters)
8 x 7.7lines/mm, 200 x 200dpi (detailed characters)
Original size: Maximum A3 or 11"x 17" (DLT)
Maximum scanning
size:
Standard: A3, 297mm x 432mm
Irregular: 297mm x 1200mm
Transmission
protocol:
Recommended: T.38 Annex protocol, TCP, UDP/IP
communication
Compatible
machines:
IP-Fax compatible machines
IP-Fax transmission
function:
Specify IP address and send fax to an IP-Fax compatible fax
through a network.
Also capable of sending fax from a G3 fax connected to the
public telephone lines via a VoIP gateway.
IP-Fax reception
function:
Receive a fax sent from an IP-Fax compatible fax through a
network.
Also capable of receiving fax from a G3 fax connected the public
telephone lines via a VoIP gateway.

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
