Ricoh Aficio MP 301SPF Service Manual

Service Program
D127/D128 5-2 SM
Selecting Programs
 When you want to jump to the program directly, confirm the item "SP Direct" [A] selected and
put the SP number you want to operate by the keypad. Then press the "#" key [B].
 When you want to select the program in the menu, touch the signs [C] to scroll through the
menu. Then touch the item you want to operate.
Specifying Values
1. After locating a program, type the keypad to put the number in as the value. To switch
between positive (plus) and negative (minus) values, press the key.
2. Press the "#" key [B] to confirm the value or the "C" key [D] to cancel.
Activating Copy Mode
You can activate the copy mode while the SP mode is running. When you do so, the copier
outputs images or patterns that help you adjust the SP setting.
1. Press the
key [E]. The copy mode is activated.
2. Specify copy settings and press the
key [E].
3. To return to the SP mode, touch the item "To SP" displayed on the upper left corner on the
panel.
 You cannot end the SP mode while the copy mode is activated.
Quitting Programs/Ending (S) SP Mode
Touch the item "Exit" displayed on the upper right corner on the panel to quit the program or end
the SP mode.
Conventions used in the tables:
 Asterisk (*): The settings are saved in the NVRAM. Most of them return to the default values
when you execute SP5-801-002. CTL indicates that the data is contained in NVRAM on the
controller board.
 DFU: The program is for design/factory use only. Do not change the settings.
 Brackets ([ ]): The brackets enclose the setting rage, default value, and minimum step with
unit ([Minimum to Maximum / Default / Step]).

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
