Card Save Function
SM 6-45 D127/D128
Trouble
shooting
6.3 CARD SAVE FUNCTION
6.3.1 OVERVIEW
Card Save:
The Card Save function is used to save print jobs received by the printer on an SD card with
no print output. Card Save mode is toggled using printer Bit Switch #1 bit number 4. Card
Save will remain enabled until the SD card becomes full, or until all file names have been
used.
Captures are stored on the SD card in the folder /prt/cardsave. File names are assigned
sequentially from PRT00000.prn to PRT99999.prn. An additional file PRT.CTL will be created.
This file contains a list of all files created on the card by the card save function.
Previously stored files on the SD card can be overwritten or left intact. Card Save SD has
"Add" and "New" menu items.
Card Save (Add): Appends files to the SD Card. Does not overwrite existing files. If the
card becomes full or if all file names are used, an error will be displayed on the operation
panel. Subsequent jobs will not be stored.
Card Save (New): Overwrites files in the card's /prt/cardsave directory.
Limitation:
Card Save cannot be used with PJL Status Readback commands. PJL Status Readbacks will
not work. In addition they will cause the Card Save to fail.
6.3.2 PROCEDURE
1. Turn the main power switch OFF.
2. Insert the SD card into the service slot of the controller board. Then turn the power ON.
To determine which slot is the service slot, please see the service manual.
3. Enter SP mode.
4. Select "Printer SP".
5. Select "SP1-001-001".
