Ricoh Aficio MP 301SPF Service Manual

System Service Mode
SM Appendix 3-9 D127/D128
Appendix:
SP Mode
Tables
SP2-XXX (Drum)
2001* Charge Roller Bias Adjust
2001 1
Setting (Copying) [–2100 to –1500 / –1700 / 10 V/step]
Adjusts the voltage applied to the charge roller for printing. The voltage
changes automatically as charge-roller voltage control works. The value here
is the base value for the charge-roller voltage control.
The value from -1800 V to -1600 V is preferable.
2001 2
ID sensor pattern [0 to 400 / 200 / 10 V/step]
Adjusts the voltage applied to the charge roller for the ID sensor pattern (as
part of charge-roller voltage correction). Setting the same value as
“SP2-201-002” is preferable.
2001 3
Temporally Input [-2500 to 0 / 0 / 10 V/step]
Inputs the voltage value. Too small value may cause the charge roller tainted.
Too large value may cause attaching carrier particles in developer, on a
printed paper. The value from – 1800 V to 1600 V is preferable.
2005* Charge Bias Correction
2005 1
Vsdp Min [0 to 100 / 90 / 1 %/step]
2005 2
Vsdp Max [0 to 100 / 95 / 1 %/step]
2005 3
Charge Roller Bias Correction (Step) [0 to 200 / 50 / 1 V/step]
Sets correction value by one step for bias adjustment to meet SP2001-001
setting value.
2102* Main Scan Adj.
2102 1 Magnification Adj. [-0.5 to 0.5 / 0 / 0.1%/step]
2102 13 Beam Pitch Dot [0 to 20 / 5 / 1 dot/step]
2005 14 Beam Pitch Subdot [0 to 15 / 3 / 1 sub-dot/step]

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
