Ricoh Aficio MP 301SPF Service Manual

SC Tables
SM 6-15 D127/D128
Trouble –
shooting
6.1.3 SC CODE DESCRIPTIONS
SC6xx
No.
Definition
Symptom Possible Cause/Countermeasure
632 C
MF accounting device error 1
The machine sends a data frame.
No normal end signal returns.
This symptom happens three
times.
 Defective or broken line
between machine and device
633 C
MF accounting device error 2
The machine is communicating
with the accounting device. The
break signal returns.
 Defective or broken line
between machine and device
634 C
MF accounting device error 3
A backup RAM error is reported
from the accounting device.
 Defective accounting device
controller
 Defective battery in the
accounting device
635 C
MF accounting device error 4
A battery voltage error is reported
from the accounting device.
 Defective accounting device
controller
 Defective battery in the
accounting device

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
