Ricoh Aficio MP 301SPF Service Manual

Overview
SM 1-5 D127/D128
Product
Information
10. Toner Collection Coil 26. Bottom Plate
11. Cleaning Blade 27. Polygon Mirror Motor
12. OPC drum 28. Laser Unit
13. Discharge Plate 29. Mixing Augers
14. Transfer Roller 30. Development Roller
15. ID (Image Density) Sensor 31. Toner Supply Bottle
16. Bypass Paper Feed Roller 32. Scanner HP Sensor
ARDF
1. Pull-out Roller 10. Registration Roller
2. Feed Roller 11. Registration Sensor
3. Friction Pad 12. Scanner Guide
4. Paper Stopper 13. ARDF drive motor
5. Pick-up Roller 14. Exit Roller
6. Original Set Feeler 15. Junction Gate
7. Original Set Sensor 16. Inverter Roller
8. Upper Cover Sensor 17. Platen Sheet
9. Original Set Tray

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
