Ricoh Aficio MP 301SPF Service Manual

System Service Mode
SM Appendix 5-3 D127/D128
Appendix:
Fax Trouble-
Shooting
Guide
5.1.3 SP3-XXX (MACHINE SET)
3 Mode No. Function
101
Service Station
001 Fax Number Enter the fax number of the service station.
102
Serial Number
000 - Enter the fax unit’s serial number.
103
PSTN-1
001 Select Line
Select the line type setting for the G3-1 line. If
the machine is installed on a PABX line, select
“PABX”, “PABX(GND)” or “PABX(FLASH)”.
002
PSTN Access
Number
Enter the PSTN access number for the
G3-1 line.
003
Memory Lock
Disabled
If the customer does not want to receive
transmissions using Memory Lock on this line,
turn this SP on.
107
IPFAX Port Settings
001 H323 Port -
002 SIP Port -
003 RAS Port -
004 Gatekeeper port -
005 T.38 Port -
006 SIP Server Port -
007
IPFAX Protocol
Priority
Select "H323" or "SIP".
201
FAX SW
001 – 032 00 – 1F -

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
