Ricoh Aficio MP 301SPF Service Manual

IP-Fax Troubleshooting
D127/D128 4-30 SM Appendix
Cannot receive by Alias Fax number.
Check Point Action
1 LAN cable connected? Check the LAN cable connection.
2 Firewall/NAT is installed?
Cannot the breach firewall. Request the
remote fax to send by using another
method (Fax, Internet Fax)
3 Gatekeeper installed correctly?
Contact the network administrator.
 The sender machine displays this
error code when the sender fax is
a Ricoh model.
4 Power to Gatekeeper switched on?
Contact the network administrator.
 The sender machine displays this
error code when the sender fax is
a Ricoh model.
5
IP address/host name of Gatekeeper
correct on the sender’s side?
Request the sender to check the IP
address/host name.
 The sender machine displays this
error code when the sender fax is
a Ricoh model.

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
