Ricoh Aficio MP 301SPF Service Manual

SC Tables
D127/D128 6-2 SM
6.1.2 ENGINE SC CODE DESCRIPTIONS
No.
Definition
Symptom Possible Cause
101 B
Exposure Lamp Error
The scanner has scanned the white
plate, but cannot detect the certain
white level.
 Defective exposure lamp
 Defective exposure lamp
stabilizer
 Defective power source harness
 Defective signal harness
 High-voltage cable leak
 Defective darkness starting
characteristic
120 B
Scanner home position error 1
The scanner home position sensor
does not detect the scanner leaving
the home position.
 Defective scanner home
position sensor
 Defective scanner home
position sensor harness
 Defective scanner motor drive
 Defective scanner motor
121 B
Scanner home position error 2
The scanner home position sensor
does not detect the scanner coming
back to the home position.
 Defective scanner home
position sensor
 Defective scanner home
position sensor harness
 Defective scanner motor drive
 Defective scanner motor
141 B
Black level correction error
The automatic adjustment has
failed to correct a current black
level to the certain level.
 Defective SBU board
 Defective relevant harness

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
