Ricoh Aficio MP 301SPF Service Manual

Bit Switches
SM Appendix 5-21 D127/D128
Appendix:
Fax Trouble-
Shooting
Guide
7
Action when a fax SC has
occurred
0: Automatic reset
1: Fax unit stops
0: When the fax unit detects a fax SC code other
than SC1201 and SC1207, the fax unit
automatically resets itself.
1: When the fax unit detects any fax SC code, the
fax unit stops.
Cross Reference
Fax SC codes - See “Troubleshooting”
5.2.2 I-FAX SWITCHES
I-fax Switch 00 [SP No. 1-102-001]
No
FUNCTION COMMENTS
Original size limitation of TX
Attachment File
These settings set the size applying to adjusting
the transmitted original data so that the destination
can receive within its capacity.
0 A4
0: Not selected
1: Selected
This function can keep a transmitting operation
from a destination’s incapacity error for the size
limitation.
1 B4
2 A3
3 Reserved (B4)
4 Reserved (A2)
5 Reserved
6 Reserved
7 Not used Do not change the factory settings.

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
