Ricoh Aficio MP 301SPF Service Manual

IFAX Troubleshooting
SM Appendix 4-21 D127/D128
Appendix:
Fax Trouble-
Shooting
Guide
4.2 IFAX TROUBLESHOOTING
 Use the following procedures to determine whether the machine or another part of the
network is causing the problem.
Communication
Route
Item Action [Remarks]
General LAN
1. Connection with
the LAN
 Check that the LAN cable is connected to
the machine.
 Check that the LEDs on the hub are lit.
2. LAN activity
 Check that other devices connected to
the LAN can communicate through the
LAN.
Between IFAX and
PC
1. Network settings
on the PC
 Check the network settings on the PC.
[Is the IP address registered in the TCP/IP
properties in the network setup correct?
 Check the IP address with the
administrator of the network.]
2. Check that PC
can connect with
the machine
 Use the “ping” command on the PC to
contact the machine.
[At the MS-DOS prompt, type ping then the IP
address of the machine, then press Enter.]
3. LAN settings in
the machine
 Check the LAN parameters
 Check if there is an IP address conflict
with other PCs.
[Use the “Network” function in the User Tools.
If there is an IP address conflict, inform the
administrator.]

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
