Ricoh Aficio MP 301SPF Service Manual

IFAX Troubleshooting
D127/D128 4-22 SM Appendix
Communication
Route
Item Action [Remarks]
Between machine
and e-mail server
LAN settings in the
machine
 Check the LAN parameters
 Check if there is an IP address conflict
with other PCs.
[Use the “Network” function in the User Tools.
If there is an IP address conflict, inform the
administrator.]
Between machine
and e-mail server
1. E-mail account
on the server
 Make sure that the machine can log into
the e-mail server.
 Check that the account and password
stored in the server are the same as in
the machine.
[Ask the administrator to check.]
2. E-mail server
 Make sure that the client devices which
have an account in the server can
send/receive e-mail.
[Ask the administrator to check.
Send a test e-mail with the machine’s own
number as the destination. The machine
receives the returned e-mail if the
communication is performed successfully.]

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
