Ricoh Aficio MP 301SPF Service Manual

Using SP Mode
D127/D128 5-10 SM
36
Cannot write module - Cause
other than E34, E35
SD update data is incorrect. The data on the SD
card is for another machine. Acquire correct
update data then install again.
40
Engine module download
failed
Replace the update data for the module on the
SD card and try again, or replace the BICU
board.
42
Operation panel module
download failed
Replace the update data for the module on the
SD card and try again, or replace the LCDC.
43
Stamp data module
download failed
Replace the update data for the module on the
SD card and try again, or replace the hard disks.
44
Controller module download
failed
Replace the update data for the module on the
SD card and tray again, or replace controller
board.
50
Electronic confirmation check
failed
SD update data is incorrect. The data on the SD
card is for another machine. Acquire correct
update data then install again.

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
