Ricoh Aficio MP 301SPF Service Manual

SC Tables
D127/D128 6-4 SM
No.
Definition
Symptom Possible Cause
162 IPC:PCIE error
-001 B
PCIE Communication error
Doesn’t occur insertion request of
linking-up from the LYRA on
startup. Or NOT the number of the
connection lanes detected is two.
 Defective IPU (BICU, IPU)
165 B
Unauthorized copy protection Failed
Detecting the ICIB wrong or NOT
attached on the copier under
setting unauthorized copy
protection on. Or detecting wrong
with the ICIB on startup.
 NOT the ICIB attached firmly.
 Defective the ICIB
202 B
Polygon motor error: Time out (On)
NOT detecting making the polygon
motor be ready in certain time after
start polygon motor up or change
the spin speed.
 Harness and the polygon motor
driver.
 Defective the polygon motor or
the polygon motor driver.
 Defective polygon motor drive
pulse output (Around polygon
control part)
 Unable to monitor XSCRDY
signal (Around polygon control
parts)
 Bad connection or
disconnection between the I/F

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
